Pressure transducers



Larger
TPX series
Product description:
TPX series is a group of transducers to measure absolute and related pressure of liquids and gases also chemicaly agressive. They are particular suitable for use in central heating and waterwork systems. Optionally, they may be equipped with radiators, wich make them applicable for measuring of medium with high temperature to 150C. Following output signals are available: 4-20mA,0-10V,0-5V and 0-20 mA using standard DIN3650 connector. If a plug-in indicator WWC1000 is added, it will results in LED output transducer with 4-20mA output signal.

Technical parameters:
Measure
ranges
▪ 0¸6 bar
▪ 0¸10 bar
▪ 0¸16 bar
▪ 0¸25 bar
Power supply▪ 10¸36 VDC for signal 4¸20 mA
▪ 15¸30 VDC for signal 0¸10 V
Output
signals
▪ 4¸20 mA   Rload ≤(Ub-10)V/0,02 A
▪ 0¸10 V      Rload ≥10kΩ
Overload4 x range
Basic error≤ 0,5% MR
Temperature
ranges
▪ ambient -20¸80░C
▪ medium -20¸80░C
▪ storage  -30¸80░C
Pressure
connectors
▪ M20x1,5
▪ G1/2"
Electrical
connectors
▪ Hirschmann DIN 43650/IP65
▪ cable with capillary/IP68
Materials▪ diaphragm 316
▪ casing 316
▪ wetted parts 316
Casing
protection

IP 65 / IP68
Applicationwater systems

                               Look at technical specification


Larger
GPX series    ATEX
Product description:
Pressure transducers series GPX are destined for measuring relative (GPXG) and absolute (GPXA) pressure of gases and liquids also also chemical aggresive. Particulary it is recommended for applications in underground mining and surface installations of plants in danger of coal dust. Measuring element of GPX is piezo resistive silicon sensor separated from measured medium by steel diaphragm. Electronic board of GPX is protected by silicone filler and closed in enclosure made of stainless steel which ensure IP65 protection grade. Electrical connector is placed in steel cover protecting it against weather conditions and mechanical damages. Pressure transducers series GPX are products within group I categhory M1, safety level ia.

Technical parameters:
Measure
ranges [bar]
▪ 0¸1 minimal
▪ 0¸1000 maximal
Power supply8¸12,5 VDC
Output
signals
▪ Voltage
  from 0,2¸1 V to 3¸5 V        Rload ≤ 3kΩ
▪ Current
  from 0,1¸1 mA to 2¸5 mA   Rload ≤ 1,2kΩ
Overloading▪ 3 x for ranges up to 400 bar
▪ 1100 bar for higher ranges
Basic error≤ 0,5% MR
Pressure
connectors
▪ Stecko
▪ M20x1,5
▪ G1/2"
Enclosure
protection

IP65,IP67 according to PN-EN 60529
Applicationundergroung mining

                               Look at technical specification
                                                            Look at certificate


Larger
NPX series
Product description:
NPX series is a basic and the most popular group of small pressure transducers with an inbuilt amplifier. These transducers are used instead of manometers. Power supply for them is 24 VDC and output signals are 4-20 mA with standard connector DIN43650. IF a plug-in indicator WWC1000 is added, it will results in a LED output transducer with 4-20 mA output signal. It is possible to make NPX transducer with any voltage output signal within range 0-10V.

Technical parameters:
Measure ranges [bar]▪ 0¸0,050 minimal
▪ 0¸1000 maximal
Power supply▪ 10¸36  VDC for 4¸20 mA
▪ 15¸30  VDC for voltage outputs
▪ 12¸30  VDC for 0¸5 V (option)
▪ 4,5¸12 VDC for 0¸3 V (low-power)
Output
signals
▪ 4¸20mA  Rload ≤(Ub-10)V/0,02A
▪ 0¸10V     Rload ≥10kΩ
▪ 0¸5V       Rload ≥10kΩ
▪ 1¸5V       Rload ≥10kΩ
▪ 0¸3V       (low-power)

* There is possible to make pressure transducers
  with any other output signals lesser than 0¸10V
  (fe. 0¸4V, 2¸8V and so on.)
Overload 4 x range
Basic error▪ ≤ 0,5% MR
▪ ≤ 0,25% MR
▪ ≤ 0,1% MR
Temperature
ranges
▪ ambient -20¸80░C
▪ medium -20¸80░C
▪ storage  -30¸80░C
Pressure
connectors
▪ M20x1,5 / M12x1,5 outer thread
▪ G¼" / G½" outer thread
▪ St. B¼" / St. B½" inner thread
▪ others to agree
Electrical
connectors
▪ Hirschmann DIN 43650/IP65
▪ circular, C091/IP54
▪ cable with capillary/IP68
▪ others to agree
Applicationmeasurement of gases and liquid pressure

                               Look at technical specification


Larger
MPX series
Product description:

NPX series is a group of miniature pressure, underpressure and absolute pressure transducers, with inbuilt amplifier. Diameter of such a transducer in its widest point is 22mm and it's total length is 110 mm. It's output signal is 4-20mA or 0-5V, conducted out throught fixed cable. Optionaly we offer 0-5V output signal applicable to work with 12 VDC power supply source (car installation).


Technical parameters:
Measure
ranges [bar]
▪ 0¸0,050 minimal
▪ 0¸200 maximal
Power supply▪ 10¸36 VDC for signal 4¸20 mA
▪ 15¸30 VDC for voltage outputs
▪ 9¸30 VDC for signal 0¸5 V(option)
Output signals▪ 4¸20 mA
▪ 0¸10 V
▪ 0¸5 V
Overload4 x range
Basic error▪ ≤ 0,5% MR
▪ ≤ 0,25% MR
Pressure connectors▪ G 1/4" outer thread
▪ M12 x 1,5 outer thread
Electrical connector
2m cable
Applicationmeasurement of gases and liquid pressure

                               Look at technical specification


Larger
PMS series

Technical parameters:
Measure
ranges [bar]
▪ 0¸0,200 minimal
▪ 0¸1 maximal
Power supply▪ 15¸30 VDC for voltage outputs
▪ 10¸36 VDC for current outputs
Output signals▪ 4¸20 mA
▪ 0¸10 V
▪ 0¸5 V
Basic error≤ 0,2% MR
Pressure connection
rubber hose connector 6x1
Electrical connection
0,5m cable
Applicationchange of pneumatic signal to electric

                               Look at technical specification


JPX series (actually not produced)
Product description:

JPX series is a group of od small, light (ap. 100g) and chip pressure transducers with 4-20mA or 0-10V output signal. This series is built using entirely ceramic sensor.


Technical parameters:
▪ Measure ranges within from -1 to 1000 bar
▪ Power supply 10¸30V DC (output signal 4¸20mA i 1¸(5) 6V
11,5¸30V DC (output signal 0¸10V
5V DC (output signal 0,5¸4,5 V)
▪ Output signal 4¸20 mA
0,5¸4,5V
1¸(5) 6V
0¸10V
▪ Allowable overload 3 x range
▪ Basic error ≤ 0,5% of measure range MR
▪ Pressure connection G 1/4"
▪ Electrical connection according to DIN43650
▪ Application measurement of gases and liquid pressure

                               Look at technical specification


Larger
PX series
Product description:
PX series is a group of can-transducers to measure pressure underpressure and absolute pressure. This series has a inbuilt amplifier converting output voltage from sensor to 4-20 mA, 0-20 mA or 0-10V (0-5V) output signal, This amplifier makes it possible to alter measure range. Power supply is here 24VDC.

Technical parameters:
Measure ranges [bar]▪ 0¸0,050 minimal
▪ 0¸1000 maximal
Power supply 15¸36V DC
Output signals▪ 4¸20 mA
▪ 0¸20 mA
▪ 20¸0 mA
▪ 0¸10 V
Basic error▪ ≤ 0,5% MR
▪ ≤ 0,25% MR
Pressure
connectors
▪  M20x1,5 / M12x1,5 outer thread
▪  G¼" / G½" outer thread
▪  St. B¼" / St. B½" inner thread
▪  others to agree
Electrical connection
clamp-rail or DIN43650
Applicationmeasurement of gases and liquid pressure

                               Look at technical specification


Larger
PXM series
Product description:
PXM is a group of transducers to measure very small pressure, underpressure and absolute pressure of mainly air and dry gases (also fumes) within range +/-1,25mbar to +/- 60mbar . This series is supplied from 5VDC power source for output signals 0,25V to 4V. Power supply for output signals 4-20mA or 0-20mA is 19,5V to 36VDC.

Technical parameters:
Measure ranges▪ ± 1,25 mbar minimal
▪ ± 25 mbar maximal
Power supply19,5¸36V DC
Output signals▪ 4¸20 mA
▪ 20¸4 mA
▪ 0¸20 mA
▪ 20¸0 mA
Basic error ≤ 0,5% MR
Pressure connectors▪ M12 x 1,5
▪ G1/4"
Electrical connection
according to DIN43650
Applicationpressure measuring in chimneys

                               Look at technical specification


Larger
PXC series
Product description:
PXC is a group of pressure transducers used in agressive enviroment (f.e chlorine) Other functions like in PX series.

Technical parameters:
Measure
ranges [bar]
▪ 0¸0,050 minimal
▪ 0¸1000 maximal
Power supply▪ 15¸36 VDC
▪ 10¸36 VDC for outputs 4¸20 mA
Output signals▪ 4¸20 mA
▪ 0¸20 mA
▪ 20¸0 mA
▪ 0¸10 V
▪ 0¸5 V
Basic error▪ ≤ 0,5% MR
▪ ≤ 0,25% MR
Pressure
connectors
▪ M20x1,5 / M12x1,5 outer thread
▪ G¼" / G½" outer thread
▪ St. B¼" / St. B½" inner thread
▪ others to agree
Electrical connection
clamp rail, according to DIN43650
Applicationagressive media measuring

                               Look at technical specification


Larger
PXT series
Product descxription:
PXT series is a group of transducers to measure media with high tempersture (about 250C). Other functions like PX.

Technical parameters:
Measure
ranges [bar]
▪ 0¸10 minimal
▪ 0¸1000 maximal
Power supply15¸36V DC
Output signals▪ 4¸20 mA
▪ 0¸20 mA
▪ 20¸0 mA
▪ 0¸10 V
▪ 0¸5 V
Basic error ▪ 0,5% MR
▪ 0,25% MR
Temperature
ranges
▪ ambient -20¸80░C
▪ medium -20¸250░C
▪ storage  -30¸80░C
Pressure
connectors
▪ M20x1,5 / M12x1,5 outer thread
▪ G¼" / G½" outer thread
▪ St. B¼" / St. B½" inner thread
▪ others to agree
Electrical connection
clamp rail or according to DIN43650
Applicationmedia with temperature up to 250░C

                               Look at technical specification


Larger
PXH series
Product description:
PXH series is a group of transducers designed to measure liquid in closed tanks. Such a transducer measures the difference of pressure between the tank's bottom and space over liquid's surface. To fix a transducer it is necessary to install a flange or thread connection on the tank's bottom or very close to it on the tank's wall. The second pressure connection of PXH must be fixed to the tank's upper part wich is always above liquid surface.

Technical parameters:
Measure ranges [bar]▪ 0¸0,050 minimal
▪ 0¸1000 maximal
Output signals▪ 4¸20 mA
▪ 0¸20 mA
▪ 20¸0 mA
▪ 0¸10 V
Basic error▪ ≤ 0,5% MR
▪ ≤ 0,25% MR
Pressure connection
DN PN standards
Electrical connection
clamp rail or according to DIN43650
Applicationmeasurement of gases and liquid presure

                               Look at technical specification


Larger
PXW series
Product description:
PXW series is a group of transducers equipped in LED indicator wich makes possible direct readout in pressure or output signal units.

Technical parameters:
Measure ranges [bar]▪ 0¸0,050 minimal
▪ 0¸1000 maximal
Power supply
[VDC]
▪ 18,5¸36 for 4¸20 mA output signal/current loop
▪ 15¸30 for all output three wires signals
Output signals▪ 4¸20 mA two wires
▪ 0¸20 mA
▪ 0¸10 V
▪ 0¸5 V

* There is possible to make pressure transducers
  with any other output signals lesser than 0¸10V
  (fe. 0¸4V, 2¸8V and so on.)
Basic error▪ ≤ 0,5% MR
▪ ≤ 0,25% MR
Indicator▪ For 4¸20 mA output signal
  - LED, red, 4 digit, 10 mm
  - error 0,1%
  - possibility to set all indications in range from
     9999 to -999
  - possibility to set a reverse indication in
     relation to analog signal ( fe. pressure and
     analog signal down, indication up)
▪ For other output signals
  - LED, red, 3½ digit, 10 mm
Temperature
ranges
▪ ambient -20¸70░C
▪ medium -20¸80░C (+ radiator -20¸150░C)
▪ storage  -30¸80░C
Temperature
compensation
ranges
0¸50░C

* Others to request
Pressure
connectors
▪ M20x1,5 / M12x1,5 outer thread
▪ G¼" / G½" outer thread
▪ St. B¼" / St. B½" inner thread
▪ others to agree
Electrical connection
according to DIN43650
Applicationmeasurement of gases and liquid presure

                               Look at technical specification


Larger
MC series- digital manometers
Product description:
MC series is a group of transducers made on base of PC series to measure pressure and underpressure. This series is equipped with 3,5 digit LCD indicator and has battery power supply. Readout of measured quantity is done during 10 seconds after pressing a key. This series may be used in place of PX, everywhere where higher performance and more precision readout is needed.

Technical parameters:
Measure ranges [bar]▪ 0¸0,050 minimal
▪ 0¸1000 maximal
Power supplybattery 9 V
Display LCD 8mm, 3.5 digit
Basic error▪ ≤ 0,5% MR
▪ ≤ 0,25% MR
Pressure
connectors
▪ M20x1,5 / M12x1,5 outer thread
▪ G¼" / G½" outer thread
▪ St. B¼" / St. B½" inner thread
▪ others to agree
Applicationmeasurement of gases and liquid presure

                               Look at technical specification


Larger
PT series
Product description:

PT series is a group of pressure and underpressure overpressure transducers without inbuilt amplifier. IT is DC supplied 4mA and has max voltage output signal from 80 to 1000mVDC. To obtain standard output signal 4-20mA, 0-20mA, 0-10V (0-5V) it works with meters series MPC.


Technical parameters:
Measure ranges [bar]▪ 0¸0,050 minimal
▪ 0¸1000 maximal
Power supplycurrent about 4 mA
Output signals▪ 0¸80 mV
▪ 0¸1000 mV
Overload4 x range
Basic error▪ ≤ 0,5% MR
▪ ≤ 0,25% MR
Pressure
connectors
▪ M20x1,5 / M12x1,5 outer thread
▪ G¼" / G½" outer thread
▪ St. B¼" / St. B½" inner thread
▪ others to agree
Electrical connection
cable in length 2 m
Applicationmeasurement of gases and liquid pressure

                               Look at technical specification
